Scannen met hand vastgehouden streepjescode lezer barcodescanner

Scannen met hand vastgehouden streepjescode lezer barcodescanner

$291-49 Others

$2550-199 Others

$23≥200Others

betaling Type:	L/C,T/T,D/P,D/A,Paypal,Others
Incoterm:	CIF,EXW,DDP
vervoer:	Ocean,Land,Air,Express,Others
Haven:	guangzhou

Option:

WNC-5060g

contact opnemen

Beschrijving

Productkenmerken

Verpakking & Levering

Beschrijving

Productkenmerken

Model: WNC-5060g

merk: Winson

Certificatie: ce, andere

Product Status: Voorraad

Types Van: Streepjescodescanner

Type Scanelement: CCD

Kleur Punt: 32 Beetje

Type Interface: USB

Plaats Van Herkomst: China

Garantieperiode (jaren): 1 jaar

Dienst Na Verkoop: Callcenter en online technische ondersteuning

Products Status: Stock

Type: Wireless 1D Scanner

Scan Element Type: CCD Barcode Scanner

Colour Depth: 32 Bit

Interface Type: usb, COM, PS/2

Max Paper Size: N/A

Optical Resolution: 1500 pix

Scan Speed: 350+50(scans/second)

Brand Name: Winson

Place Of Origin: Guangdong, China

Warranty(Year): 1-Year

After-sales Service: Call Center And On-Line Technical Support

Naam van product: Wireless 1D Scanner

Product Type: 1D CCD Barcode Scanner

Photo Sensor: CCD linear sensor

Communications: Wired transmission mode

Communication Frequency: BT 4.0

Voltage Requirement: 5VDC±10%

Print Contrast: 20%UPC/EAN 13(13mil)

Current: Max:135mA

Light Source: 632nm red LED

Dimensions: 90mm*67mm*168mm

Verpakking & Levering

Verkoopeenheden	:	unit
Pakkettype	:	Aangepaste verpakking (onderhandeld)

The file is encrypted. Please fill in the following information to continue accessing it

Beschrijving

Barcode Scanner

2d CMOS Barcode Scanner Application Fields: Parcel Locker, Supermarket Locker, Ticket Machine, Self-Service Vending Machine, Intelligent Express Cabinet, Kiosk, Locker, Access Control Machine, Self-Service Store, Check-In Machine, Bank Teller Machine, Factory Assembly Lijn, logistiek, ziekenhuis, PDA, enz.

Snel scannen zwart witte hand vastgehouden streepjescode lezer 1D laser USB Wried Barcode Barcode Scanner -module

Ondersteuning van de secundaire ontwikkeling - De instructie van de seriële poortontwikkeling is voltooid om te voldoen aan elke soort interactieve vraag van hostcomputerbeheersing.

Met Mini USB -ontvanger, plug and play, ergonomisch ontwerp, comfortabel om de QR -scannermodule vast te houden .

Barcode Scanner

winson company

Product detail

Technical Specifications
Wireless specifications
Communication mode		Wired transmission mode/ Wireless Read-time mode&Inventory mode/Cache mode
Communication frequency		BT 4.0(2.402 to 2.480GHz Adaptive frequency hopping)
Transmission range		≤10M(In empty area 15M)
Battery capacity		1500mAh (Lithium battery)
Charge Time from Empty to Full Charge		4.5H
Scans per Battery Charge		30,000 (1 scan per second)
Memory		100,000@13Byte barcode
Electrical Characteristics
Interface Supported	USB HID KEYBOARD
Input Voltage	DC 5V±10%
Current	Max:135mA
Optical Characteristics
Image Sensor	CCD Linear Sensor
Sensor Resolution	2500pixels
Light Source	632nm Red LED
Performance Characteristics
Decoding rate:	350 scans/second±20 scans/second
Scanning Angle	Pitch angle:±35°;Skew angle:±75°;Tilt angle:±40°
Min Resolution	0.105/4mil(PCS 0.9)
Min .PCS value	>25%UPC/EAN 13(13mil)
Language	Multiple Languages
Data Edition	Support for custom data output
Decode Capability	EAN13,EAN8,UPC A,UPC E,CODABAR(NW-7),CODE 39,CODE 93,INTERLEAVED 2OF5,STANDARD 2OF5,MATRIX 2OF5,CODE 128,EAN/UCC 128,CODE 11,CHINESE POST
Physical Characteristics
Dimensions	Scanner:90mm67mm168mm(LWH)
Weight	Scanner:160g
Indicator	Beeper, LED
Environmental Characteristics
Temperature	-20° to 65°C / -4° to 149°F(operation) /-30° to 70°C /-22° to 158°F(storage)
Humidity	5 - 90% (operation) ) 5 - 90% (storage)
Ambient Light:	Up to 80,000 lx
Shock Drop Test	1.5m drop onto concrete surface
