Gratis monster 1D CCD Laser 2D Scanner Supermarket

Gratis monster 1D CCD Laser 2D Scanner Supermarket

$0.1-5 /unit

betaling Type:	L/C,T/T,D/P,D/A,Paypal,Others
Incoterm:	FOB,CIF,EXW,DDP
Min. orde:	1 unit
vervoer:	Ocean,Land,Air,Express,Others
Haven:	guangzhou

Option:

CMC-551/2D
CMI-8000/1D
CMI-8060/1D

contact opnemen

Beschrijving

Productkenmerken

Verpakking & Levering

Beschrijving

Productkenmerken

Model: CMC-551/2D CMI-8000/1D CMI-8060/1D

merk: Wiinson

Certificatie: ce

Product Status: Voorraad

Types Van: Streepjescodescanner

Type Scanelement: CCD

Kleur Punt: 32 Beetje

Type Interface: USB

Plaats Van Herkomst: China

Garantieperiode (jaren): 1 jaar

Dienst Na Verkoop: Callcenter en online technische ondersteuning

Private Mold: Yes

Products Status: Stock

Type: Barcode Scanner

Scan Element Type: Cmos

Colour Depth: 32 Bit

Interface Type: Usb, Rs232

Max Paper Size: N/A

Optical Resolution: 640X480 pixels

Scan Speed: 350 ±50 scans/second

Place Of Origin: Guangdong, China

Warranty(Year): 1-Year

After-sales Service: Call Center And On-Line Technical Support

Software Development Kit (SDK): NO

Color: Black, Blue

Product Type: QR Code Scanner

Interface: USB HID KEYBOARD/USB VCP or RS-232

Photo Sensor: CMOS array sensor

Voltage Requirement: DC5V±10%

Light Source: Red LED

Dimensions: 90mm*67mm*168mm

Weight: 130g

Indicator: Beeper, LED

Verpakking & Levering

Verkoopeenheden	:	unit
Pakkettype	:	Aangepaste verpakking (onderhandeld) 1 stcs/box, 20/50pcs/doos
Afbeeldingsvoorbeeld	:

The file is encrypted. Please fill in the following information to continue accessing it

Beschrijving

Gratis monster 1D CCD/laser/2D Scanner Supermarket Barcode Reader Scanner Scanner met laser

Desktop 2D Barcode Scanner Secundaire ontwikkeling ondersteunen-De instructie van de seriële poortontwikkeling is voltooid om te voldoen aan elke soort van host computerbesturing interactieve vraag mini Auto-scanning module .

SCAN QR -code Desktop kan worden aangepast aan de vraag van de klant.

SCAN-MODULE TOEPASSINGSTOPPLAATS VIELDS: Pakketkast, Supermarkt Locker, Ticket Machine, Self-Service Vending Machine, Intelligent Express Cabinet, Kiosk, Locker, Access Control Machine, Self-Service Store, Check-In Machine, Bank Teller Machine, Factory Assembly Line , logistiek, ziekenhuis, enz.

Productomschrijving

Barcode Reader Gratis monster 1D CCD/Laser/2D Scanner Supermarket Barcode Reader Scanner Portable Scanners

Gratis monster 1D CCD/Laser/2D Scanner Supermarket Barcode Reader Scanner Portable Scanners

winson company

Product detail

Electrical Characteristics
Interface Supported	USB HID KEYBOARD/USB VCP or RS-232
Input Voltage	DC 5V
Current	150mA
Performance Characteristics
Sensor	640×480 CMOS
Illumination	White LED
Focus	Red LED
Scanning Angle	Pitch angle:+55°
	Skew angle:+360°
	Tilt angle:+55°
Field of view	36°(H),27°(V)
Reading accuracy	≥5mil
Decode Capability	1D:Code 128,Ean-13 ,Ean-8,UPC-E,UPC-A,ITF-25(Interleaved 2 0f 5),Code39,Code93,Codabar 2D:QR Code,Data Matrix,PDF417
Environmental Characteristics
Temperature	operation:-20°C to 60°C
	storage:-40°C to 80°C
Humidity	operation:5%~95% (no condensation)
Ambient light	0~100,000LUX
Decoding Depth of Field
Symbology	Resolution	Barcode number	Barcode width
Code128	13mil	10	4.3x3.1cm
Code39	5mil	7	3.5x1.19cm
EAN13	13mil	13	4.5x2.69cm
QR Code	15mil	30	1.9x1.85cm
Data Marix	10mil	30	4.5x1.16cm
PDF 417	6.67mil	30	4.0x10.5cm
