Winson Wired Barcode Scanner Module USB/RS232

Winson Wired Barcode Scanner Module USB/RS232

$164.51-49 Others

$145.550-199 Others

$130.5≥200Others

betaling Type:	L/C,T/T,D/P,D/A,Paypal,Others
Incoterm:	FOB,CIF,EXW,DDP,CFR
vervoer:	Ocean,Land,Air,Express,Others
Haven:	guangzhou

Option:

MK20-980

contact opnemen

Beschrijving

Productkenmerken

Verpakking & Levering

Beschrijving

Productkenmerken

Model: MK20-980

merk: Winson

Certificatie: ce, andere

Product Status: Voorraad

Types Van: Streepjescodescanner

Type Scanelement: CCD, CMOS

Kleur Punt: 32 Beetje

Type Interface: USB

Plaats Van Herkomst: China

Garantieperiode (jaren): 1 jaar

Dienst Na Verkoop: Callcenter en online technische ondersteuning

Private Mold: Yes

Products Status: Stock

Type: Barcode Scanner

Scan Element Type: Cmos

Colour Depth: 32 Bit

Interface Type: usb, TTL-232

Max Paper Size: N/A

Optical Resolution: 800*1000 pix

Scan Speed: 350±50 (scans/second)

Brand Name: Winson

Place Of Origin: Guangdong, China

Warranty(Year): 1-Year

After-sales Service: Call Center And On-Line Technical Support

Software Development Kit (SDK): NO

Naam van product: embedded in Barcode scan Module

Interface: USB/RS-232

Photo Sensor: CMOS array sensor

Voltage / Current: DC 5V; Max 224ma

Dimensions (W X D X H): 100 mmx82mmx34mm

Weight: 128g

certificaat: Ce, Rohs

Verpakking & Levering

Verkoopeenheden	:	unit
Pakkettype	:	Brown Box Packing of aangepaste verpakking (onderhandeld)
Afbeeldingsvoorbeeld	:

The file is encrypted. Please fill in the following information to continue accessing it

Winson Wired Barcode Scanner Module USB/RS232 2D Barcode -lezer voor liftdeurslot1



Beschrijving

Scanner met laserondersteuning secundaire ontwikkeling - de instructie van de seriële poortontwikkeling is voltooid om aan elke soort interactieve vraag van de hostcomputerbeheersing te voldoen.

2D Stationaire barcodescanner kan worden aangepast aan de vraag van de klant.

Winson MK20-980 Barcode-scannermodule voor kiosk lange-afstandsbalkcode lezer

Wired Barcode Scanner Module

winson company

Product detail

Technical Specifications
Electrical Characteristics
Interface Supported		USB HID KEYBOARD; RS232;
Input Voltage		DC 5V±10%
Current		Max:224mA
Optical Characteristics
Image Sensor		CMOS Array Sensor
Sensor Resolution		1280X800 Pixels
Performance Characteristics
Field of View		36°(H),23°(V)
Reading accuracy		≥10 mil
Language		Multiple Languages
Data Edition		Support for custom data output
Decode Capability		1D: Code 128, Code 93, Code 39, ITF-6, ITF-14, Interleaved of 5, Industrial 2 of 5, Matrix 2 of 5, Standard 2 of 5, GS1 Databar, EAN-13, Code 11, MSI-PLESSEY,Code 11,PLESSEY,EAN-8,UPC-E,ISBN,CODEBAR 2D:QR Code
Physical Characteristics
Dimensions		100mm82mm34mm(LWH)
Weight		128g
Indicator		Beeper, LED
Environmental Characteristics
Temperature		0° to 50°C (operation) /-5° to 55°C (storage)
Humidity		20 - 85% (operation) ) 20 - 90% (storage)
Shock Drop Test		1.5m drop onto concrete surface
Decoding Depth of Field
Symbology	Resolution		texture	Barcode width	Nearest	Farthest
QR Code	44.17mil		On the screen	2.3 x 2.3cm	5cm	100cm
QR Code	77.50mil		On the screen	4.0 x 4.0cm	11cm	180cm
Code 39	15.83mil		On the screen	5.3 x 1.5cm	4cm	60cm
Code 128	19.58mil		On the screen	6.8 x 2.0cm	5cm	85cm
