NFC ingebed 2D -afbeelding OEM Barcode Scanner -module

NFC ingebed 2D -afbeelding OEM Barcode Scanner -module

$40.91-49 Others

$35.550-199 Others

$29.9≥200Others

betaling Type:	L/C,T/T,Paypal
Incoterm:	FOB,CIF,EXW,DDP
vervoer:	Ocean,Land,Air,Express,Others
Haven:	guangzhou

Option:

Z4S-320

contact opnemen

Beschrijving

Productkenmerken

Verpakking & Levering

Beschrijving

Productkenmerken

Model: Z4S-320

merk: Winson

Certificatie: ce

Product Status: Voorraad

Types Van: Streepjescodescanner

Type Scanelement: CCD

Kleur Punt: 32 Beetje

Type Interface: USB

Plaats Van Herkomst: China

Garantieperiode (jaren): 1 jaar

Dienst Na Verkoop: Callcenter en online technische ondersteuning

Private Mold: Yes

Products Status: Stock

Type: Barcode Scanner

Scan Element Type: Cmos

Colour Depth: 32 Bit

Interface Type: usb, TTL-232

Max Paper Size: N/A

Optical Resolution: 640*480 pix

Scan Speed: 350±50 (scans/second)

Brand Name: Winson

Place Of Origin: Guangdong, China

Warranty(Year): 1-Year

After-sales Service: Call Center And On-Line Technical Support

Software Development Kit (SDK): NO

Color: White

Naam van product: embedded scan Module

Interface: USB/TTL/RS232

Photo Sensor: CMOS array sensor

Voltage / Current: DC 5V ±5%; Max 140ma

Dimensions (W X D X H): 53.5mm x 36mm x 16mm

Weight: 15g

Field Of View: 74°(H),58°(V)

certificaat: Ce,Rohs

Verpakking & Levering

Verkoopeenheden	:	unit
Pakkettype	:	Brown Box Packing of aangepaste verpakking (onderhandeld)
Afbeeldingsvoorbeeld	:

The file is encrypted. Please fill in the following information to continue accessing it

NFC ingebed 2D -afbeelding OEM Barcode Scanner Module QR Barcode Scanner -module voor Factory1



Beschrijving

product beschrijving

Specificatie

Interface	USB(standard) TTL(optional) RS232(optional) RS485(optional)
Voltage requirement	DC 5V±5%(USB,TTL,RS232,RS485)
Current consumption	135mA(Max) 74mA(Min)
Light source	4 white LEDs (green LED can be selected)
Photo sensor	CMOS array sensor
CMOS array sensor	640×480 pixels(300,000 pixel)
Field of View	55° (H) x 44° (V)
Support code	1D:Code128,EAN-13,EAN-8,Code39,Code93,UPC-A,UPC-E,Codabar,Interleaved 2 of 5,Industrial 2 of 5,ITF-6,ITF-14,ISBN,GS1-128,UCC/EAN-128,GS1 Databar,Matrix 2 of 5,Standard 2 of 5,Plessey,MSI-Plessey 2D: QR Code,PDF417,Micro QR,Micro PDF,DataMatrix,Aztec Maxicode , hanxin
Decode angle	Pitch angle:±30° Skew angle:±40° Tilt angle:±180°
