USB embedded bircode scanner

$502-49 Others

$4850-199 Others

$45≥200Others

betaling Type:	L/C,T/T,D/A,Paypal,Others
Incoterm:	FOB,CIF,EXW,DDP
vervoer:	Ocean,Air,Express,Land
Haven:	guangzhou

Option:

Z11-321

contact opnemen

Beschrijving

Productkenmerken

Verpakking & Levering

Beschrijving

Productkenmerken

Model: Z11-321

merk: Winson

Certificatie: ce

Product Status: Voorraad

Types Van: Streepjescodescanner

Type Scanelement: CCD, CMOS

Kleur Punt: 32 Beetje

Type Interface: USB

Plaats Van Herkomst: China

Garantieperiode (jaren): 1 jaar

Dienst Na Verkoop: Callcenter en online technische ondersteuning

Private Mold: Yes

Products Status: Stock

Type: Barcode Scanner

Scan Element Type: Cmos

Colour Depth: 32 Bit

Interface Type: Usb, Rs232

Max Paper Size: N/A

Optical Resolution: 1280X800 Pix

Scan Speed: 350+-50 Scans/second

Brand Name: Winson

Place Of Origin: Guangdong, China

Warranty(Year): 1-Year

After-sales Service: Call Center And On-Line Technical Support

Software Development Kit (SDK): NO

Color: Black

Interface: RS-232/USB HID KEYBOARD/USB VCP

Light Source: 8 white LEDs

Voltage Requirement: DC5V±10% ; Max 135ma

Decode Capabilities: both 1D and 2D

Scan Angle: Pitch angle:±65° Skew angle:±60° Tilt angle:±180°

Reading Accuracy: DP:1D Linear:≥3 mils 2D:≥5 mils

Dimensions: 78mm x 67mm x 54mm

certificaat: Ce

Verpakking & Levering

Verkoopeenheden	:	unit
Pakkettype	:	Brown Box Packing of aangepaste verpakking (onderhandeld) 1 stcs/doos, 20/50 stcs/doos
Afbeeldingsvoorbeeld	:

The file is encrypted. Please fill in the following information to continue accessing it

USB Embedded Wired Barcode Scanner 1D 2d Omni 360 Bar Code Scanner Reader1



Beschrijving

product beschrijving

Specificatie

Interface Supported	USB/ RS-232/TTL
Input Voltage	DC 5V±5%
Current	Max:135mA
Image Sensor	CMOS Array Sensor
Sensor Resolution	640X480 Pixels
Light Source	White LED
Scanning Angle	Pitch angle:±30°;Skew angle:±40°;Tilt angle:±180°
Field of View	68°(H),54°(V)
Min Resolution	≥5mil（PCS 0.9）
Min .PCS value	〉25% UPC/EAN 13（13mil）
Decode Capability	1D：Code 128, Code 39, Code93，EAN-8, EAN13, UPCA, UPCE, ISBN, ISSN 2D：QR code
Dimensions	78mm67mm54mm(LWH)
Temperature	-10°∽60°C / -14°∽140°F(operation) /-30°∽70°C /-22°∽158°F(storage)
Humidity	5 - 90% (operation) ) 5 - 90% (storage)
Shock Drop Test	1.2m drop onto concrete surface
